Lapp Unitronic DeviceNet Thick+Thin, 24 AWG, 4 Core, 2 Pair, Violet, Network Cable, PE PVC FR, With Tin-Plated Copper Braiding
| 2170343Product Specifications
| Manufacturer Product Name | UNITRONIC BUS DN THIN Y Bus cable, DeviceNet, Fixed Installation, Nominal characteristic impedance: 120, 1x2xAWG24 + 1x2xAWG22, PVC, Flame-retardant, Oil-resistant, violet, 6.9 mm, cUL listed |
|---|---|
| Brand | LAPP Kabel |
| Model | Unitronic Device Net |
| Sub Family | Unitronic Device Net |
You're Protected With Every Order
Trusted since 1967 · 57+ years in electrical
100% Genuine Products
Direct from brand-authorised sources.
Manufacturer Assured
Warranty as per manufacturer terms.
GST Invoice
Compliant invoice with every order.
Technical Support
Expert help for product selection.
Business Features
Exclusive benefits for bulk buyers.
3-Day Replacement
Easy replacement on eligible items.
Need Help With This Product?
Product Selection
Technical Guidance
Bulk Orders & Quotations
Business Purchases
Order Support
About this product
More Information
| Manufacturer Product Name | UNITRONIC BUS DN THIN Y Bus cable, DeviceNet, Fixed Installation, Nominal characteristic impedance: 120, 1x2xAWG24 + 1x2xAWG22, PVC, Flame-retardant, Oil-resistant, violet, 6.9 mm, cUL listed |
|---|---|
| Brand | LAPP Kabel |
| Model | Unitronic Device Net |
| Sub Family | Unitronic Device Net |
| Reference No | 2170343 |
| Manufacturer Details | Lapp India Pvt. Ltd. Plot No.98, J & K Jigani Industrial Area, II Phase, BANGALORE SOUTH - 560 105, India |
| Manufacturer Customer Care | [email protected], 1800-309-1111 |
| Conductor Size | 24 AWG |
| No of Core | 4 Core |
| Conductor Material | Tin-Plated Copper |
| Insulation Type | PE PVC FR |
| Cable Colour | Violet |
| Shielding Type | Tin-Plated Copper Braiding |
| Shape of Cable | Round |
| Resistance Towards | UV-Resistant, Oil-Resistant, PWIS-Free |
| Minimum Bending Radius | 15 X Outer Diameter |
| Temperature Range | -25 °C To 80 °C |
| Core identification | Colours |
| Fieldbus or Ethernet | Devicenet |
| Application Area | Fixed Installation |
| Features | Shielded, Flame-Retardant |
| Nominal Diameter | 6.9 Mm |
| Certifications | CE Marked, EAC Certified, UL Listed, cUL Listed |
| OFC impedance | 120 Ω |
| No of Pair | 2 Pair |
| Core Stranding Type | Twisted-Pair |
| Conductor Stranding Type | 19-Wire |
₹654.57
Incl. of Taxes
₹554.72
/Mtr
+ GST ₹99.85
|
₹1,007.04
₹853.42
-35.00% Off
Out of stock
Dispatch
Tentative by 06 July
Delivery
Click for Delivery Timeline
Express delivery timelines based on your location:
| Region / State Group | Express (Fast) |
|---|---|
| Karnataka (within state) | 1 day |
| Tamil Nadu, Kerala, Andhra Pradesh, Telangana | 1-2 days |
| Goa | 2-3 days |
| Maharashtra - Mumbai & Pune | 1-2 days |
| Maharashtra - Rest of State | 2-3 days |
| Gujarat, Rajasthan | 3-5 days |
| Madhya Pradesh, Chhattisgarh | 3-4 days |
| Delhi (NCR), Haryana, Punjab | 3-4 days |
| Uttar Pradesh, Himachal, Uttarakhand | 3-5 days |
| Odisha, West Bengal | 3-4 days |
| Assam & North-East (NE states) | 3-5 days |
| J&K / Ladakh | 4-6 days |
Express Delivery Information
- • Delivery times are estimated and may vary based on location
- • Orders dispatched from Yeshwanthpur Warehouse, Bangalore
- • Express delivery available for orders placed before 2 PM
- • Remote areas may require additional 1-2 days
Product PDF
